Operating Modes
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
684
of 820
4.8
122.3 Master position revolutions
Indication of the current revolution of the master axis in a 32 bit resolution.
122.4 Master position angle
Indication of the current angle of the master axis in a 32 bit resolution per revolution.
122.5 Active cam segment
This parameter can be read cyclically. It defines the curve segment which is currently pro-
cessed.
122.6 Sequence change at first
With this cyclically writable parameter the coupling/decoupling point of the sequence
change is specified. This parameter is used together with
Z122.41–.
The parameter is split:
The sequence change is indicated here. The change is carried out by a rising edge of bit 5
of
Z108.1– "Control word 1".
122.7 Start cam segment
Number of the polynomial which represents the start position of the master axis and the
drive.
122.8 Start position master revolution
Revolution of the master axis at the beginning of the starting segment.
Sequence change >122.6<
16 bit segment responded to 16 bit segment following
