Preparations
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
18
of 820
2.4
2.4 Preparations
Specimen installation of a decentralized drive BM25xx.
The prerequisite for the commissioning is that assembly and installation have been car-
ried out correctly.
1 Make sure that the assembly is carried out correctly and, in particular, that all safety
regulations have been observed (see Assembly in the Operating Manual for the
b
maXX
®
2500 basic unit).
2 Make sure that the installation is carried out correctly and, in particular, that all safety
regulations have been observed (see Installation in the Operating Manual for the
b
maXX
®
2500 basic unit).
3 ProDrive must be installed on the PC/Laptop.
During commissioning you can, among other things, enter motor and encoder data in
the operating software or correct incorrect values. So that you can perform the com
-
missioning efficiently, it is advantageous to have all the data at hand for the commis-
sioning. Data for Baumüller motors are available in the form of a "Motor Database"
within the operating software.
4 Make sure that all the necessary data are at hand.
Motor data
(Identification
plate)
These data can be found, e.g., on the identification plate for the motor that you are using
for the commissioning.
The motor database is used in this example; the values in the table are provided only for
checking purposes.
NOTE
Pictures for the next work steps can be found in the Operating Manual for the
b
maXX
®
2500 basic unit.
Name Value, e.g. Used for entering in the parameter list /parame-
ter
Motor type, designation DSD Parameter list/Motor configuration
Z107.2– Motor type
Nominal voltage U
N
330 V Parameter list/Motor configuration
Z107.8– Motor nominal voltage
Nominal current I
N
4,0 A Parameter list/Motor configuration
Z107.9– Motor nominal current
Nominal speed n
N
3000 rpm Parameter list/Motor configuration
Z107.7– Motor nominal speed
