Set Value Generators
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
408
of 820
4.6
4.6.1.4 Description of the Parameters
110.1 Status
Status of the ramp function generator
Comments:
m Bit 13:
This bit is changed, if the interpolator set value cycle ramp function generator cycle
is active. The bit is deleted at constant input set value or set value failure. The ramp
function generator input set value is interpolated from the set value cycle to the ramp
function generator cycle (1 ms).
Bit Meaning
0 1: Ramp generator is switched on
3 … 1 Reserved
4 1: FG output is set internally to 0 (FG INHIBIT)
5 1: FG has been halted on the ramp (FG STOP)
6 1: FG input is set internally to set value 0 (FG ZERO)
7 1: Quick Stop ramp is active (FG QSTOP)
8 1: Ramp-up is active
9 1: Ramp-down is active
10 1: Braking ramp ended
11 Reserved
12 1: FG output = FG input (set value reached)
13 Status input set value
0: Input set value is constant
1: Input set value is interpolated
14 1: Controlled stop is active
15 1: SS1 stop is active
16 1: Set Value inhibit has blocked negative set value (see 110.2 Mode Bit 0)
17 1: Set Value inhibit has blocked positive set value (see 110.2 Mode Bit 1)
18 1: Run in negative direction with hardware limit switch prevented
19 1: Run in positive direction with hardware limit switch prevented
20 Absolute value limitation of the input set value to an allowed minimum
value Z110.16–
21 Absolute value limitation of the input set value to an allowed maximum
value Z110.15–
31 … 22 Reserved
