4.4.10.2 Parameter overview
Functional block: DigInputs [116]
4.4.10.3 Parameter description
116.1 Status digital inputs
Status of the digital inputs. Bits 19 ... 16 display the hardware status, i.e., whether the in-
put has been set active. Bits 3 ... 0 show the logical states of the inputs according to their
configured inversion (see Bit 15 in each case in the Mode Digital Input 1
Z116.2–, Mode
Digital Input 2 Z116.8–, etc. parameters).
Number Name Type Min Max Default Value Unit Factor
Read only Storage DS Support Cyclic Write
116.1 Status digital inputs DWORD 0 0xFFFFFFFF 0 1:1 X
116.2 Mode digital input 1 WORD 0 0xFFFF 0 1:1 X
116.4 Target number digital input 1 UDINT 0 0xFFFFFFFF 0 1:1 X
116.5 Bit selection digital input 1 DWORD 0 0xFFFFFFFF 0 1:1 X
116.6 Set bit pattern for LOW state
digital input 1
DWORD 0 0xFFFFFFFF 0 1:1 X
116.7 Set bit pattern for HIGH state
digital input 1
DWORD 0 0xFFFFFFFF 0 1:1 X
116.8 Mode digital input 2 WORD 0 0xFFFF 0 1:1 X
116.10 Target number digital input 2 UDINT 0 0xFFFFFFFF 0 1:1 X
116.11 Bit selection digital input 2 DWORD 0 0xFFFFFFFF 0 1:1 X
116.12 Set bit pattern for LOW state
digital input 2
DWORD 0 0xFFFFFFFF 0 1:1 X
116.13 Set bit pattern for HIGH state
digital input 2
DWORD 0 0xFFFFFFFF 0 1:1 X
116.14 Mode digital input 3 WORD 0 0xFFFF 0 1:1 X
116.16 Target number digital input 3 UDINT 0 0xFFFFFFFF 0 1:1 X
116.17 Bit selection digital input 3 DWORD 0 0xFFFFFFFF 0 1:1 X
116.18 Set bit pattern for LOW state
digital input 3
DWORD 0 0xFFFFFFFF 0 1:1 X
116.19 Set bit pattern for HIGH state
digital input 3
DWORD 0 0xFFFFFFFF 0 1:1 X
116.20 Mode digital input 4 WORD 0 0xFFFF 0 1:1 X
116.22 Target number digital input 4 UDINT 0 0xFFFFFFFF 0 1:1 X
116.23 Bit selection digital input 4 DWORD 0 0xFFFFFFFF 0 1:1 X
116.24 Set bit pattern for LOW state
digital input 4
DWORD 0 0xFFFFFFFF 0 1:1 X
116.25 Set bit pattern for HIGH state
digital input 4
DWORD 0 0xFFFFFFFF 0 1:1 X
