4.7.5.7 Parameter Overview of the Two-level Controller
Functional blocks: Fb2LevelCtrlAbs [151] 
Fb2LevelCtrlRel [152]
Number Name Type Min Max Default Value Unit Factor
Read only Storage DS Support Cyclic Write
151.1 Mode WORD 0 0x3F 0 1:1 X
151.2 Status WORD 0 0xFFFF 0 1:1 X
151.3 Input UDINT 0 0xFFFFFFFF 0 1:1 X
151.5 Lower threshold absolute FLOAT -5000000000 5000000000 0 1:1 X
151.6 Upper threshold absolute FLOAT -5000000000 5000000000 0 1:1 X
151.9 Axis selection output param-
eter
UINT 0 1 0 1:1 X
151.10 Target number UDINT 0 0xFFFFFFFF 0 1:1 X
151.11 Bit selection DWORD 0 0xFFFFFFFF 0 1:1 X
151.12 Bit pattern LOW DWORD 0 0xFFFFFFFF 0 1:1 X
151.13 Bit pattern HIGH DWORD 0 0xFFFFFFFF 0 1:1 X
151.14 Lower threshold absolute
UDINT
UDINT 0 0xFFFFFFFF 0 1:1 X
151.15 Upper threshold absolute
UDINT
UDINT 0 0xFFFFFFFF 0 1:1
152.1 Mode WORD 0 0x7 0 1:1 X
152.2 Status WORD 0 0xFFFF 0 1:1 X
152.3 Input UDINT 0 0xFFFFFFFF 0 1:1 X
152.4 Relative compare value UDINT 0 0xFFFFFFFF 0 1:1 X
152.5 Lower threshold absolute FLOAT -5000000000 5000000000 0 1:1 X
152.6 Upper threshold absolute FLOAT -5000000000 5000000000 0 1:1 X
152.7 Lower threshold relative FLOAT -5000000000 5000000000 0 1:1 X
152.8 Upper threshold relative FLOAT -5000000000 5000000000 0 1:1 X
152.9 Axis selection output param-
eter
UINT 0 1 0 1:1 X
152.10 Target number UDINT 0 0xFFFFFFFF 0 1:1 X
152.11 Bit selection DWORD 0 0xFFFFFFFF 0 1:1 X
152.12 Bit pattern LOW DWORD 0 0xFFFFFFFF 0 1:1 X
152.13 Bit pattern HIGH DWORD 0 0xFFFFFFFF 0 1:1 X
152.14 Lower threshold absolute
UDINT
UDINT 0 0xFFFFFFFF 0 1:1 X
152.15 Upper threshold absolute
UDINT
UDINT 0 0xFFFFFFFF 0 1:1 X
152.16 Lower threshold relative
UDINT
UDINT 0 0xFFFFFFFF 0 1:1 X
152.17 Upper threshold relative
UDINT
UDINT 0 0xFFFFFFFF 0 1:1 X
