System
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
80
of 820
4.3
4.3 System
4.3.1 System control
4.3.1.1 Parameter overview
Functional blocks: System control 1 [1]
System control 2 [2]
FbVersion [102]
FbSystem [139]
FbSysPerformance[158]
Number Name Type Min Max Default Value Unit Factor
Read only Storage DS Support Cyclic Write
1.1 System clock UDINT 0 0xFFFFFFFF 0 s 1:1 X
1.2 System ticks RT1 UDINT 0 0xFFFFFFFF 0 1:1 X
1.3 System ticks RT2 UDINT 0 0xFFFFFFFF 0 1:1 X
1.8 RT0-cycle time FLOAT 62.50 1000.00 250.00 µs 1:1 X
1.10 Task fieldbus cycle time UDINT 125 8000 1000 µs 1:1 X
102.1 Firmware number UDINT 0 0xFFFFFFFF 0 1:1 X
102.2 Firmware version UDINT 0 0xFFFFFFFF 0 1:1 X
102.3 Firmware type UDINT 0 5 0 1:1 X
102.4 Firmware build number UDINT 0 0xFFFFFFFF 0 1:1 X
102.5 Firmware name STRING 1:1 X
102.6 Firmware version information STRING 1:1 X
102.7 Firmware time stamp STRING 1:1 X
102.8 Bootloader0 version STRING 1:1 X
102.9 Bootloader1 version STRING 1:1 X
102.10 Fpga Id UDINT 0 0xFFFFFFFF 0 1:1 X
102.11 Bootloader flags UDINT 0 0xFFFFFFFF 0 1:1 X
102.13 Expected system Fpga Id UDINT 0 0xFFFFFFFF 0 1:1 X
102.14 FPGA version UDINT 0 0xFFFFFFFF 0 1:1 X
102.15 FPGA firmware number UDINT 0 0xFFFFFFFF 0 1:1 X
102.18 Fieldbus controller firmware
number
UDINT 0 0xFFFFFFFF 0 1:1 X
102.19 Fieldbus controller firmware
version
UDINT 0 0xFFFFFFFF 0 1:1 X
102.20 Fieldbus controller firmware
version time stamp
STRING 1:1 X
102.21 Fieldbus controller firmware
type
UDINT 0 0xFFFFFFFF 0 1:1 X
102.22 Fieldbus controller firmware
build number
UDINT 0 0xFFFFFFFF 0 1:1 X
102.23 Board data command UINT 0 0x1000 0 1:1
