Baumuller b maXX BM3000 User Manual

Description of the Software Modules and Parameters
Parameter manual b maXX BM3000
Document no.: 5.12001.07
79
of 820
4
Name = Common parameter name for ProDrive and Parameter Manual
Type = Data type
INT Integer 16 bit 
DINT Integer 32 bit 
UINT Unsigned Integer 16 bit 
UDINT Unsigned Integer 32 bit 
WORD Word 16 bit 
DWORD Double Word 32 bit 
FLOAT Float 32 bit 
STRING String (characters) 
RECORD Composite data type (Struct, Array, etc.)
Min = Range of values of the parameter, minimum value at internal standardization
Max = Range of values of the parameter, maximum value at internal standardization
Default Value = Default value at internal standardization
Unit = Unit of the parameter for display in ProDrive
Factor = Conversion factor between display ProDrive and internal standardization
X in column „Read only“ = Parameter is read-only
X in column „Storage“ = Parameter will be stored in Flash
X in column „DS support“ = Parameter will be stored in data sets of the 
Flash
X in column „Cyclic Write“ = Parameter may be written cyclic, e.g. using 
process data of the fieldbus
Example:
Number Z110.5– Functional block ramp function generator, parameter 5
Name Input 16 bit Name of parameter, display ProDrive english
Type INT Integer 16 bit
Min ... Max -16384 to 16384 Range of values
Default Value 0 Default value 0 at internal standardization
Unit % Unit % for ProDrive
Factor 4000
hex
: 100% 100% in ProDrive correspond to 16384 internal
The parameter is writable, cyclic writable, it will be stored namely in all data sets.
Number Name Type Min Max Default Value Unit Factor
Read only Storage DS Support Cyclic Write
110.5 Input 16 bit INT -16384 16384 0 % 4000
hex
:
100%
X X X
