Configuration
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
94
of 820
4.4
4.4.1.3 Description of the Parameters
129.3 Hardware Id
The hardware identifier has the format:
33.YYNN.[S]BB.A.01 Example: 33.1110.S01.C.01
130.25 Mains failure delay UINT 0 6000 0 ms 1:1 X
130.29 Chopper threshold FLOAT 400 780 780 V 1:1 X
130.34 Status STO module UINT 0 0xFFFF 0 1:1 X
130.35 Mains failure detection mode UDINT 0 0xFFFFFFFF 0 1:1 X
130.36 Relative Udc threshold for
mains failure
FLOAT 10 90 80 % 1:1 X
130.37 Udc threshold for mains fail-
ure
FLOAT 10 1000 450 V 1:1 X
130.38 Udc hysteresis for mains fail-
ure
FLOAT 10 500 50 V 1:1 X
130.39 Udc autodetect FLOAT 0 1000 0 V 1:1 X
130.41 Actual PWM frequency UINT 2 16 8 kHz 1:1 X
175.3 Max. device control cabin
temperature
UINT 0 55 40 Grad
C
1:1 X
175.4 Max. device altitude UINT 0 5000 1000 m 1:1 X
175.5 Max. device mains voltage UINT 0 530 400 V 1:1 X
175.6 Max. device DC link voltage UINT 0 760 540 V 1:1 X
175.7 PU max.continuous current
actual value
FLOAT 0 1000 4 A 1:1 X
175.8 PU I2t max. continuous cur-
rent actual value
FLOAT 0 1000 4 A 1:1 X
Abbreviation Meaning
YY Year Example: 2011
NN Sequential number Example: 10
S STO module available
BB Assembly variant Example: 01
A Revision number Example: C
01 Technical status Example: 01
