Baumuller b maXX BM3000 User Manual

Description of the Software Modules and Parameters
Parameter manual b maXX BM3000
Document no.: 5.12001.07
95
of 820
4
129.4 Hardware name
129.5 Current scaling gain
Standardization factor for current measurement, depends on the power unit.
129.6 DC scaling gain
Standardization factor for the DC link voltage, depends on the power unit.
129.7 Main voltage scaling gain
Standardization factor for the supply voltages, depends on the power unit.
129.8 Current converter configuration
Factory settings for the configuration
129.9 IGBT dead time
Dead time for the power unit transistors.
129.10 Min. pulse suppression
Minimum pulse suppression is used to prevent extremely short duty cycles for pulse width
modulation, such as may occur when outputting large voltages. Instead of generating ex
-
tremely short On/Off switching pulses, the switching state of the IGBTs is extended to the
next PWM period. This will further increase the maximum possible voltage setting. PWM
voltage pulses that are shorter than the parameter value will be suppressed.
Abbreviation Meaning
BM3201 BG0, without STO module
BM3211 BG1, without STO module
BM3301 BG0, with STO module
BM3311 BG1, with STO module
