Description of the Software Modules and Parameters
Parameter manual b maXX BM3000
Document no.: 5.12001.07
231
of 820
4
Deactivation of the "Test input" is done in two ways:
m by deactivating the "Test input on/off" check box; Parameter 125.1 or 125.2 should
then be set to 0. As a result, the value 0 appears in the corresponding "Source Param
-
eter Number" box.
m by directly writing a different ID in the "Source Parameter Number" box. The corre-
sponding check box must also be automatically deactivated.
4.4.13.3 Parameter overview
Functional block: FbVisu [125]
Number Name Type Min Max Default Value Unit Factor
Read only
Storage
DS Support
Cyclic Write
125.1 Visu Channel 1 source
parameter id
UDINT 0 4294967295 0 1:1 X
125.2 Visu Channel 2 source
parameter id
UDINT 0 4294967295 0 1:1 X
125.3 Visu command UINT 0 1 0 1:1 X
125.4 Visu status UINT 0 1 0 1:1 X
125.7 Visu task no UINT 0 3 3 1:1 X
125.8 General scaling FLOAT -5000000000 5000000000 1.000000e+00 Unit/V 1:1 X
125.9 Force scaling FLOAT 0 2147483648 1.000000e+00 N/V 1:1 X
125.10 Current scaling FLOAT -5000000000 5000000000 1.000000e+00 A/V 1:1 X
125.11 Voltage scaling FLOAT -5000000000 5000000000 1.0 V/V 1:1 X
125.12 Position scaling FLOAT -5000000000 5000000000 3.600000e+01 Unit/V 1:1 X
125.13 Speed scaling FLOAT -5000000000 5000000000 1.000000e+03 Unit/V 1:1 X
125.14 Acceleration scaling FLOAT -5000000000 5000000000 4 Unit/V 1:1 X
125.15 Torque scaling FLOAT -5000000000 5000000000 1 Nm/V 1:1 X
125.17 Test Signal amplitude FLOAT 0 5000000000 0 V 1:1
125.18 Correction gain channel 1 FLOAT 0 5000000 1.000 1:1 X
125.19 Correction gain channel 2 FLOAT 0 5000000 1.000 1:1 X
125.20 Offset channel 1 FLOAT -10.0 10.0 0 V 1:1 X
125.21 Offset channel 2 FLOAT -10.0 10.0 0 V 1:1 X
125.22 Test signal FLOAT -5000000000 5000000000 0 V 1:1
