Management
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
362
of 820
4.5
4.5.2 Data Set Management
The device data set management is described in this chapter. You will learn how to create
and change over data sets without ProDrive.
All the parameters which are assigned to the data set management system can be found
at
ZParameter overview– from page 369.
4.5.2.1 General
The total configuration, thus all storable parameters, of the device is referred to as Pa-
rameter set. The parameter set includes the axis independent parameter and the axis
dependent parameter of all axes.
Tha data set dependent parameter of an axis are referred to as Data set.
The parameters for configuring the device are stored in its Flash memory.
Some of these parameters are implemented as data set parameters, i.e., up to 7 different
configurations can be stored. It is also possible to switch between these data sets during
operation.
4.5.2.2 Command interface
The data set management system can be accessed via ProDrive or via Fieldbus.
The following actions are possible:
m Storing parameter set
m Loading parameter set
m Creating and deleting data sets
m Initializing data sets
m Switching between (already created) data sets
m Copying data sets
m Storing data sets
m Loading data sets
A command is activated either by ProDrive or by writing a command code to the Com-
mand parameter Z105.1–. Additional auxiliary parameters supplement the command in-
terface.
When operating with ProDrive, data set command codes and data set auxiliary parame-
ters must be ignored as they automatically take over the user interface.
The parameter Z105.2– Status displays the instantaneous processing state of the com-
mand interface and also any error messages from the previous command.
