4.4.21.2 Description of the Parameters
165.1 Mode
Mode for the function - configurable status word.
165.2 Configurable status
This parameter shows the status of the parameterized bits of the source parameters. This
parameter shows the results from the logic operations.
The particular status bit is deleted, if the following occurs:
m The associated channel (source parameter to >0.0<) is switched off
m The associated logic operation (Z165.1– to 0) is switched off
If the function of the logic operations is switched off completely via the Z165.1– Mode
bit 0 = 0, the state of the completely configurable status is frozen at the shut-off time.
If only the function of all logic operations is switched off via the Z165.1– Mode bit 1 = 0,
the status of the logic operation outputs (bit no. 16 to 30) is frozen only.
Number Name Type Min Max Default Value Unit Factor
Read only Storage DS Support Cyclic Write
165.1 Mode DWORD 0 0xFFFFFFFF 0 1:1 X X
165.2 Configurable status DWORD 0 0xFFFFFFFF 0x0 1:1 X
165.3 Source numbers RE-
CORD
0 0xFFFFFFFF 0 1:1 X
165.4 Bit mode RE-
CORD
0 0xFFFF 0 1:1 X
165.5 Logic functions RE-
CORD
0 6 0 1:1 X
165.6 Latch DWORD 0 0xFFFFFFFF 0 1:1 X
Bit No. Meaning
0 Control of the entire function “configurable status word”
0: Configurable Status including the links is switched off; the status of all
status bits of the Z165.2– is frozen.
1: Activation of “configurable status”.
1 Control of the logic operations
0: All operating functions are switched off; the status of the status bits 16
to 30 of the Z165.2– is frozen.
1: Activation of the parameterized operations
