System
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
90
of 820
4.3
4.3.2 Display
4.3.2.1 Parameter overview
Functional block: FbDisplay [135]
4.3.2.2 Description of the Parameters
135.1 Mode Error Display
Number Name Type Min Max Default Value Unit Factor
Read only
Storage
DS Support
Cyclic Write
135.1 Mode error display UDINT 0 0xFFFFFFFF 0x1010000 1:1 X
Bit Value Meaning
15 ... 0 Reserved
23 ... 16 0 Only errors (with a response set in the parameters) are displayed:
the error-LED H14 (axis
1) or H24 (axis 2) is on in case of error.
If only warnings or errors without a response set in the parameters
are triggered, the error-LED flashes
1 All errors and warnings are displayed; the error-LED is on perma-
nently in case of error or warning.
24 Activation of LED Power On (H12 (axis 1) or H22 (axis 2), if power
on
0 LED is on permanently
1 LED flashes (life signs)
31 ... 25 Reserved
