Baumuller b maXX BM3000 User Manual

Description of the Software Modules and Parameters
Parameter manual b maXX BM3000
Document no.: 5.12001.07
173
of 820
4
106.13 Motor angle UDINT 0 4294967295 0 Inc 1:1 X
106.14 Motor angle SI FLOAT 0 360 0 Grad 1:1 X
106.15 Revolution overflow counter UDINT 0 0x7FFFFFFF 0 1:1
106.16 Revolution overflow counter
max value
UDINT 0 0x7FFFFFFF 0 1:1 X
106.20 Offset sinus INT -2048 2047 0 1:1 X
106.21 Offset cosinus INT -2048 2047 0 1:1 X
106.22 Gain sinus UINT 0 2047 1024 1:1 X
106.23 Gain cosinus UINT 0 2047 1024 1:1 X
106.24 Sinus signal INT -32768 32767 0 1:1 X
106.25 Cosinus signal INT -32768 32767 0 1:1 X
106.43 Resolver mode WORD 0x0 0xFFFF 0x3 1:1 X
106.44 Resolver excitation set ampli-
tude
UINT 0 100 55 % 1:1 X
106.45 Resolver excitation act ampli-
tude
UINT 0 100 0 % 1:1 X
106.46 Resolver set phase offset UINT 0 0xFFFF 20 µs 1:1 X
106.47 Resolver actual phase offset UINT 0 0xFFFF 0 µs 1:1 X
106.52 Resolver phase synchroniza-
tion
UINT 0 124 0 µs 1:1 X
106.60 SSI mode UDINT 0 0xFFFFFFFF 0x00004000 1:1 X
106.61 SSI status UDINT 0 0xFFFFFFFF 0 1:1 X
106.62 SSI bits angle UINT 0 31 12 1:1 X
106.63 SSI bits revolutions UINT 0 31 12 1:1 X
106.64 SSI angle UDINT 0 0xFFFFFFFF 0 Inc 1:1 X
106.65 SSI revolutions UDINT 0 0xFFFFFFFF 0 1:1 X
106.70 Encoder excentricity angular
phase shift
UDINT 0 0xFFFFFFFF 0 Inc 1:1 X
106.71 Encoder excentricity angular
amplitude
UDINT 0 0xFFFFFFFF 0 Inc 1:1 X
106.72 State of encoder optimization DINT 0 0xFF 0 1:1 X
106.75 Maximal harmonic UINT 0 3 0 1:1 X
106.76 Amplitudes of the harmonics UDINT 0 0xFFFFFFFF 0 Grad 1:1 X
106.77 Phases of the harmonics UDINT 0 0xFFFFFFFF 0 Grad 1:1 X
106.81 DSL communication error
counter
UDINT 0 0xFFFFFFFF 0 1:1 X
137.1 Number of pulses UDINT 0 524288 1024 1:1 X
137.2 Number of revolutions UINT 0 0xFFFF 1 1:1 X
137.3 Encoder data selection UINT 0 0xFFFF 4 1:1 X
137.4 Notch position offset UINT 0 0xFFFF 0 1:1
137.5 M0-Offset angle UDINT 0 0xFFFFFFFF 0 Inc 1:1 X
137.6 M0-Offset revolution UDINT 0 0xFFFFFFFF 0 1:1 X
137.7 M0-Sector position initiator DINT -2147483648 2147483647 0 1:1
137.8 Encoder operation time UDINT 0 0xFFFFFFFF 0 1:1
137.9 Time first commissioning UDINT 0 0xFFFFFFFF 0 1:1
137.10 Time last refresh UDINT 0 0xFFFFFFFF 0 1:1
137.20 Type name STRING 1:1 X
137.21 Serial number STRING 1:1 X
