Baumuller b maXX BM3000 User Manual

Description of the Software Modules and Parameters
Parameter manual b maXX BM3000
Document no.: 5.12001.07
123
of 820
4
19.10 Motor nominal torque current
Display of the nominal torque current I
sq-nom
, comprised of the motor nominal current I
nom
(Z107.9–) less the field current.
ASM (I
sd-nom
= Magnetizing current Z107.14–):
SM (I
sd-nom
= 0, or << I
nom
, is assumed):
19.11 Ke factor in V/Nnom
Ke factor in V/N
nom
or the effective value of the phase-to-phase induced voltage at the
nominal speed. It results from the parameters
Z107.7– Nominal speed and Z107.20– Ke
factor (in V/1000 rpm) at a magnetic flux = 100%.
When the Ke factor Z107.20– in the enabled state is changed then the internally used
value in the controller is smoothed in order to reduce interferences in the controller. The
temporal change of the smoothing Ke factor can be monitored in the parameter 19.11.
19.12 Frequency of the current filter
Cut-off frequency of the iq set value filter. The filter is switched off by setting this param-
eter to 0.
19.17 Isq additive set value
Additional set value for current.
19.18 Phi electric
Visualization of the electrical angle (360 degrees = 0xFFFF).
I
sq-nom
I
2
nom
I
2
sd-nom
–=
I
sq-nom
I
nom
=
