Description of the Software Modules and Parameters
Parameter manual b maXX BM3000
Document no.: 5.12001.07
161
of 820
4
171.21 State identification nonlinearity
Status of the identification of the Lq, Ld and Ke curve families
Value Meaning
0 Inactive
1 Initialization
2 Determination of the maximum speed for the identification
3 Variation of Id
4 Variation of Iq
5 Wait until speed is equal zero
6 Acceleration and switching to measurement, if speed greater than 10%
and speed controller is limited
7 ... 8 Reserved
9 Measurement of Uq, Ud and speed
10 ... 15 Calculation of the magnetic flux
16 ... 17 Determination of the sampling time
18 Reset of the parameters used for the measurement
19 Calculation of the inductance, if the needed current is too high
20 End
21 Error
22 Timeout
23 Calculation of Ld
24 Recalculation of the tables
