Configuration
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
176
of 820
4.4
14.12 Error count upper limit
Display of how often the maximum threshold (sin²+cos²) has been exceeded.
14.13 Max error count sector
Set value for the sector monitoring of the encoder signals. At activated monitoring an error
message is generated corresponding to the preset numbers of sector errors.
14.14 Error count sector
Display of how often a sector error has been detected.
14.15 Max error count incremental encoder
Set value for the incremental encoder monitoring. At activated monitoring an error mes-
sage is generated corresponding to the preset numbers of incremental encoder errors.
14.16 Error count incremental encoder
Display of how often an incremental encoder error has been detected.
14.17 Encoder error mask
Bit field for selecting the active encoder monitors.
When Bit 0 = 1 the encoder monitoring is activated. With Bits 1 to 6 it must be set which
of the several monitorings operate.
When Bit 0 = 0, the encoder monitoring is disabled completely.
Bit no. Meaning
0 0: Encoder monitoring switched off
1: Encoder monitoring switched on
1 Monitoring of maximum signal amplitude active
2 Monitoring of minimum signal amplitude active
3 Monitoring of sectors active
4 Monitoring of the square-wave incremental encoder active
