Configuration
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
186
of 820
4.4
_________________________________________________________________
– Z106.43– = 0x0093: Resolver reevaluation, resolver frequency = 8 kHz with syn-
chronization on the fieldbus and automatic amplitude and phase setting
Here the required phase shift to the DSP interrupt with >106.52< can be set.
– Z106.43– = 0x0092: Resolver reevaluation = 8 kHz with synchronization on the
fieldbus. However, with an automatic phase setting and an manual amplitude set-
ting. Here the following procedure shall be complied with:
1. Setting of Z106.20– (Z106.21–) = 0 and Z106.22– (Z106.23–) = 1024.
2. Set the excitation set-amplitude manually by Z106.44–, until the value is
displayed at Z14.3– by about 85%.
3. Set the required phase shifting to the DSP interrupt by >106.52<.
106.60 SSI mode
Setting of transmission and the data format:
Bit Meaning
9 ... 0 Reserved
13 - 10 Baud rate
Value Meaning
0 100 kHz
1 199 kHz
2 399 kHz
3 1,014 MHz
4 1,974 MHz
5 ... 15 Reserved
14 Binary code / Gray code
0: Transmitted in binary code
1: Transmitted in Gray code
15 Reserved
16 Parity
0: Transmitted without parity bit
1: Transmitted with parity bit
17 Even parity / odd parity
0: Even parity (bit 16 is set)
1: Odd parity (bit 16 is set)
31 ... 18 Reserved
