Configuration
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
260
of 820
4.4
Bit Meaning
Encoder 1
0…2 Measurement "Encoder 1 with Trigger digital input TP1"
0 Activation channel measurement positive edge
(Enc1TrDi1PosValRev/Enc1TrDi1PosValPhi)
0: switch off
1: switch on
1 Activation channel measurement negative edge
(Enc1TrDi1NegValRev/Enc1TrDi1NegValPhi)
0: switch off
1: switch on
2 Trigger frequency
0: one-time trigger
a new measure does not occur until measuring encoder has been reac-
tivated with P124.2
1: Continuous triggering 
Measurements always occur; however, within a sampling cycle of the
module (1 ms), only the first event will be triggered.
3…5 Measurement "Encoder 1 with Trigger digital input TP2"
3 Activation channel measurement positive edge
(Enc1TrDi2PosValRev/Enc1TrDi2PosValPhi)
0: switch off
1: switch on
4 Activation channel measurement negative edge
(Enc1TrDi2NegValRev/Enc1TrDi2NegValPhi)
0: switch off
1: switch on
5 Trigger frequency
0: one-time trigger
a new measure does not occur until measuring encoder has been reac-
tivated with P124.2
1: Continuous triggering 
Measurements always occur; however, within a sampling cycle of the
module (1 ms), only the first event will be triggered.
6…
12
Measurement "Encoder 1 with Trigger Zero Pulse"
6 Activation channel measurement positive edge
(Enc1TrZpPosValRev/Enc1TrZpPosValPhi)
0: switch off
1: switch on
7 Activation channel measurement negative edge
(Enc1TrZpNegValRev/Enc1TrZpNegValPhi)
0: switch off
1: switch on
8 Reserved
