Baumuller b maXX BM3000 User Manual

Configuration
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
272
of 820
4.4
150.12 Output lower limit PID con-
troller 1
FLOAT -5000000000 5000000000 0 1:1 X
150.13 Set value PID controller 1 FLOAT -5000000000 5000000000 0 1:1 X
150.14 Actual value PID controller 1 FLOAT -5000000000 5000000000 0 1:1 X
150.15 Output PID controller 1 FLOAT -5000000000 5000000000 0 1:1 X
150.16 Integral term PID controller 1 FLOAT -5000000000 5000000000 0 1:1
150.17 Mode PID controller 2 WORD 0 0xFFFF 0 1:1 X
150.18 Status PID controller 2 WORD 0 0xFFFF 0 1:1 X
150.20 Source number set value PID
controller 2
UDINT 0 0xFFFFFFFF 0 1:1 X
150.21 Source number actual value
PID controller 2
UDINT 0 0xFFFFFFFF 0 1:1 X
150.22 Target number output PID
controller 2
UDINT 0 0xFFFFFFFF 0 1:1 X
150.23 P-gain PID controller 2 FLOAT 0 100000 0 1:1 X X
150.24 Integral action time PID con-
troller 2
FLOAT 0.000001 100000 0.01 s 1:1 X
150.25 Derivative time PID controller
2
FLOAT 0 100000 0 s 1:1 X
150.26 Pt1 time constant PID con-
troller 2
FLOAT 0 20 0 s 1:1 X
150.27 Output upper limit PID con-
troller 2
FLOAT -5000000000 5000000000 0 1:1 X
150.28 Output lower limit PID con-
troller 2
FLOAT -5000000000 5000000000 0 1:1 X
150.29 Set value PID controller 2 FLOAT -5000000000 5000000000 0 1:1 X
150.30 Actual value PID controller 2 FLOAT -5000000000 5000000000 0 1:1 X
150.31 Output PID controller 2 FLOAT -5000000000 5000000000 0 1:1 X
150.32 Integral term PID controller 2 FLOAT -5000000000 5000000000 0 1:1
