Description of the Software Modules and Parameters
Parameter manual b maXX BM3000
Document no.: 5.12001.07
393
of 820
4
140.2 Status
States of the Signal bus lines:
11 Evaluation of the signal "Chopper Resistor on":
0: Signal is evaluated
1: Signal is not evaluated
15 ... 12 Reserved
Bit no. Meaning
NOTE!
The Signal bus must be always activated and the Supply ready for use signal must
always be evaluated at external supply (Mode bit
0 and bit 10 to 0).
The switch off of the Signal bus is provided only for special applications, e.g. if the
supply does not support a Signal bus. If the Signal bus or the evaluation of the Sup
-
ply ready for use signal is deactivated, it must be ensured via the control, that the
drive is only enabled, if the supply is ready. Otherwise the supply unit can be dam
-
aged in this case.
Bit no. Meaning
4 ... 0 Reserved
5 Chopper resistor on
6 Reserved
7 Supply operationally ready
