Description of the Software Modules and Parameters
Parameter manual b maXX BM3000
Document no.: 5.12001.07
461
of 820
4
18.43 Bandwith x2 act value notch filter
Bandwith of the speed actual value notch filter in Hz.
18.44 x2 speed actual value unfiltered
Unfiltered speed actual value
18.45 Isq set value unlimited
Display of the current set value [in A] at the output of the speed controller or with torque
control.
18.50 Isq set value for torque control
During the current control operating mode (Z109.2– = -2), the controller receives the
torque current set value from this writable parameter. The parameter value for the torque
current can be entered for example by parameter interface (ProDrive), analog inputs or
by Fieldbus.
Standardization:
100% = Max. torque current Z19.8–
18.54 Position act value rev+angle
The parameter displays the actual „mixed“ position actual value in 32 bit resolution. The
lower 16 bits correspond to the angle and the upper 16 bits to the revolutions.
NOTE!
The parameter must continuously be understood as the percentage set of the "Max.
torque current"
Z19.8–. The parameter can be entered and displayed in ampere (this
is demanded as an auxiliary setting) at ProDrive. The value which was entered in am-
pere however can change during the operation because the reference value can
change because of the field weakening or the external total current limit. See param
-
eters Z19.8– and Z138.1–.
