Time-Optimized Positioning with Smoothing = 10 ms (filter element)
Figure 183: Time-optimized positioning with smoothing
Figure 184: Jerk-free positioning (S-Curve speed profile) with jerk = 0.12 Inc/ms
3
Figure 185: Jerk-free positioning (S-Curve speed profile) with jerk = 0.63 Inc/ms
3
v
0
200
400
600
800
1000
1200
1 21 41 61 81 101 121 141 161 181 201 221
Sampling steps
