Error messages and troubleshooting
Parameter manual b maXX BM3000
Document no.: 5.12001.07
755
of 820
5
705 Motor temperature for characteristic
curve of ASM slip invalid, lower than -
50°C or higher than 200°C
The motor temperature that is measured via the KTY encoder is
monitored for asynchronous motors due to slip characteristic curves
If the temperature is lower than -50°C or higher than 200°C, the tem
-
perature values are assumed to be invalid and the error will be trig-
gered.
m Cause:
The KTY motor temperature encoder was incorrectly connected
or not at all connected.
n Remedy through:
n Check connections and cable of KTY motor temperature
encoder.
n Monitoring may be deactivated for intended operation without
temperature encoder.
m Cause:
KTY motor temperature encoder defective.
n Remedy through:
n A defective KTY motor temperature encoder generally requires
motor replacement.
n Monitoring may be deactivated for intended operation without
temperature encoder.
m Cause:
Evaluation switch of the KTY motor temperature encoder in the
drive controller is defective.
n Remedy through:
n Drive controller replacement.
n Monitoring may be deactivated for intended operation without
temperature encoder.
No response
709 Motor excess temperature The measured temperature is higher than permitted Pulse block
710 Motor Temperature Threshold1
exceeded
Motor Temperature Threshold1 exceeded No response
711 Motor Temperature Threshold 2
exceeded
Motor Temperature Threshold 2 exceeded No response
712 Short circuit on temperature encoder Short circuit on temperature encoder Pulse block
713 Temperature encoder is not connected Temperature encoder is not connected Pulse block
714 Motor excess temperature PTC resistor Motor excess temperature PTC resistor encoder addressed Pulse block
716 Notch position not found An error occurred while identifying the rotor position of the synchro-
nous machine. The rotor position has not been identified.
Pulse block
717 Excess voltage occurred during resis-
tance measurement
Error during identification of motor parameters. The maximum per-
mitted phase voltage (= 80 V) was exceeded during the resistance
measurement.
m Possible cause:
Incorrect motor nominal current setting in Parameter 107.09.
Pulse block
718 Voltage limit accessed during resis-
tance measurement
Error during identification of motor parameters. The voltage limit was
reached during the resistance measurement.
m Possible causes:
Incorrect motor nominal current setting in Parameter 107.09.
- Voltage insufficient.
Pulse block
Error
num-
ber
Brief error text Error description Default set-
ting for
Error
Response
