System
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
84
of 820
4.3
102.11 Bootloader flags
Flags from the Bootloader / Bootfile Management:
102.13 Expected system Fpga version
Expected version of the system FPGA.
102.14 FPGA version
Display of the FPGA version in the format Major[2] . Minor[2] . Fix[2]
102.15 FPGA firmware number
Baumüller internal FPGA Firmware number
102.18 Fieldbus controller firmware number
Baumüller internal fieldbus firmware number
Bit # Meaning
0 Current BL1 was faulty, fallback used
1 Current firmware was faulty, fallback used
2 Current FPGA was faulty, fallback used
3 Current communication firmware was faulty, fallback used
4 New BL1 file has been saved in Flash
5 New firmware file has been saved in Flash
6 New FPGA file has been saved in Flash
7 New communication firmware file has been saved in Flash
8 Fallback of the communication firmware was faulty, communication firm-
ware has not been downloaded
9 Error at download communication firmware (timeout), communication
firmware has not been downloaded
