Chapter 7 Chemical Delivery and Pumping Station
Water and Soap to Various Brushes Connections - Standard
Water and Soap Circuit Connection Overview – Center Pod
Main Water into
Universal Manifold
from Boom
Soap Pump
Universal Manifold
Water Feed Assembly
Water and Soap Out to the Exit Wheels
Soap / Water Out to Machine
Water and Soap Out to the Entrance Wheels
Water Supply to
Water Feed Assembly
Entrance Wheel ASCO™ Valve
Soap / Water ASCO™ Valve
Exit Wheel ASCO™ Valve
Water and Soap Out to the Top Wheel
Top Wheel ASCO™ Valve
