Chapter 7 Chemical Delivery and Pumping Station
Electrical Distribution Block Connections
This section will explain all the feeds to and from the Electrical Distribution Block used for the Chemical
Discharge.
Electrical Distribution Block Overview
The Electrical Distribution Block is where the connections are made to the Chemical Discharge from the MCC.
Either a single or dual plug can connect to this block. Depending on your purchased options, you may have either type
in each location. The electrical distribution block image below shows the destinations of dual plug feeds.
See the supplied prints and “Electrical Drawings” for more details.
Electrical Distribution Block Center Pod
