INSTALLATION AND STARTUP
1MANUL220 Belanger, Inc.® * PO BOX 5470. * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681 4-61
Chapter 4 Frame and Carriage Assembly
Loading Optional Top Wheel Whisper Wheel®
The FreeStyler® Whisper Wheel® cleaning material ships separately and must be installed in the field.
To install the Whisper Wheel® cleaning material, the Top Wheel hub must be removed. Two people
are needed to remove the hub safely.
You will need 10 feet of rope to tie the Top Wheel frame down and prevent it from rocking during the
installation.
You will also need two work horses to set the hub on while loading the material.
Quick Fill Overview
Parts Required
• 2 – 9329 (Compression Cap)
• 6 - 1FSTNR-HH328 (3/8-16 x 2” bolts)
• 6 - 1WASHR-LC291 (3/8” lock washers)
• 6 – 1WASHR-FL498 (3/8” flat washers)
To Next Page
