INSTALLATION AND STARTUP
1MANUL220 Belanger, Inc.® * PO BOX 5470 * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681 19-3
Chapter 19 Trades
Boom Feeds
Hoses shown below are to be field supplied.
The Boom Feed requires a 3/4” hydraulic hose and runs from the Wall Manifold to the Optional Thru-Wall Kit.
The Wall Manifold requires a 1” hydraulic hose and runs from the Lexair™ Valve Assembly atop the Pumping
Station to the inlet of the Wall Manifold.
Note: All hoses shown below are field supplied.
The above image shows the hose connection from the Pumping Station Manifold to the Wall Manifold
