Belanger FreeStyler - Parts Identification

INSTALLATION AND STARTUP
1MANUL220 Belanger, Inc.® * PO BOX 5470. * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681 8-7
Chapter 8 MixStir® Options Triple Foam and High-Pressure Wax
Parts Identification
Part Number: 106999
HydroMinder Assembly
Check Valve Assembly
Check-Valve:
Normally open, no spring. If
Reclaim is installed, this Check-
Valve will prevent pressure from
coming backward through the
Asco™ Valve and overflowing
the wax tank
Float Check-Valve Assembly:
Normally open, no spring. If the
wax tank fails to fill, the float
ball will close the suction line
and prevent the main pump
from ingesting excessive air
Float
Main water feed
Float Ball
(1BALL-PL150)
Float Check Body
(6880)
Bulkhead Gasket
(1GASKT650)
1NUT-JM500
Check Valve
(1VALVE-WA211)
Petcock
(1VALVE-WA225)
1/4-20 Retainer Bolt
(1FSTNR-HH116)
Check Valve
Assembly
Water inlet valve
