Belanger FreeStyler - Exit Wheel Circuit Overview - Driver Side Pod

INSTALLATION AND STARTUP
21-2 Belanger, Inc.® * PO BOX 5470. * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL220
Chapter 21 Pneumatic and Hydraulic Connections
Exit Wheel Circuit Overview – Driver Side Pod
Note: The Driver Side cylinder for the Exit Wheel has (1) Reid switch.
Elbow
Hydraulic Extend
Fitting
Air Solenoid for
Exit Wheels
Pneumatic
Extend
Pneumatic
Retract
Hydraulic Retract
8 Port Valve Manifold
Hydraulic Extend
Elbow
Hydraulic Retract
Fitting
