Belanger FreeStyler - Driver Side Pod Air Solenoid Valves Overview

INSTALLATION AND STARTUP
21-4 Belanger, Inc.® * PO BOX 5470. * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL220
Chapter 21 Pneumatic and Hydraulic Connections
Driver Side Pod Air Solenoid Valves Overview
Soap Foam
Optional Air Concentrator
Drip Reduction
Optional Triple Foam
Optional HydroBlade® Select
Optional Wheel Cleaner Deselect
Entrance Wheel/ Driver Side
Entrance Wheel/ Passenger Side
High / Low Pressure
Entrance Hydraulics
Exit Wheels
Top Wheel
Drive Forward/Stop Light
Back Up Light
Connections to Euro Block in Driver Side
Shuttle Valve
High / Low Pressure
Entrance Wheel
/ Driver Side
Entrance Hydraulics
Top Wheel
Exit Wheels
Entrance Wheel/
Passenger Side
Soap Foam
Optional Air Concentrator
Optional Triple Foam
Connections to
Euro Block in
Driver Side Pod
See the
Image Above
Optional Wheel
Cleaner Deselect
Spare
Optional HydroBlade® Select
8 Port Valve
Manifold
4 Port Valve Manifold
