Chapter 16 Signage Options
Depending on the sign option selected, there are three signs that may need to be installed. The
“Wait/Go” (Wash In Use/Enter Wash) sign is wall mounted and the “Navigational” (Drive
Forward/Stop/Back Up) sign is floor mounted. The optional “Combination” sign is customizable. The
“Navigational” sign and optional “Combination” sign are shipped with a stand to be floor mounted. This
section covers only the basic feeds to the available sign packages. Some items may differ from your
signs. See your site-specific prints for details.
Wait/Go Sign
1) Supply 120VAC to the junction box mounted on the housing of the Wait/Go Sign. Refer to your electrical
drawings.
Navigational Sign
1) Supply 120VAC to the junction box mounted on the housing of the Navigational Sign. Refer to your electrical
drawings.
