INSTALLATION AND STARTUP
13-2 Belanger, Inc. ®* PO BOX 5470. * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL220
Chapter 13 Water Softener Option
Getting Started
The following procedures have been developed to assist during the installation of your water softener.
ALL STATE AND LOCAL PLUMBING CODES MUST BE IDENTIFIED AND MET, including, but not limited to:
• Distances that equipment may be placed from the main panel box and electrical outlets.
• Air gaps that must be provided for all drain lines.
Pre-installation Review
Before beginning the installation of the system, confirm the system configuration to be installed and
components that have been ordered. Please review the system specification sheet that includes the required
components.
A review of the customer’s facility is also recommended. Pay special attention to critical operating data that
could affect the function of the system.
Water pressure to the system affects the performance during regeneration. The system will not operate
properly if the inlet pressure fluctuates below a dynamic pressure of 25 psi.
Note: This minimum pressure must always be maintained to the system.
Note: If the pressure fluctuates below 25 psi, a booster pump may be purchased.
Do not use this system when water pressure exceeds 125 psi or when water temperature exceeds 120° F.
Do not install the water softener in an area where the temperature can cause the unit to freeze. Damage to
the system will result.
It is recommended that a certified installer perform the installation. Failure to install the system as instructed
will void the warranty.
Proper ventilation must be provided when using PVC cleaner or glue.
Use a ladder for all work overhead that is beyond your natural reach. If working continuously at a height of six
feet or more, the appropriate safety devices must be employed.
Use an appliance dolly when transporting equipment on stairways.
When soldering, the following must be met and followed:
• Use LEAD FREE solder.
• PVC containers and other flammable materials must be closed or removed to prevent fire or explosions.
• Loose clothing (i.e.: shirts tails, sleeves, etc.) should not be worn or should be addressed before using a
torch for soldering.
• The customer must be notified if you will be disabling smoke alarm(s) during installation. Be sure to
reconnect the smoke alarm(s).
• A scorch pad must be used to protect any surface that may be exposed to a torch flame or excessive
heat. Wear protective eyewear while installing to prevent eye injury caused by splattering soldering
materials or metal/plastic shavings.
• Do not solder brass adapters while inserted in the module main base. Damage to the plastic and rubber
parts may occur due to the heat and may result in water damage.
• The materials used in the soldering process may attack certain types of plastics. Take care during the
installation process to assure that solder and flux do not come in contact with the media tanks, the control
module and related plastic components.
