INSTALLATION AND STARTUP
1MANUL220 Belanger, Inc.® * PO BOX 5470. * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681 3-1
Chapter 3 Getting Started
Installation Overview
Working Envelope: Overview
Ideal bay width is 16’-6”. Minimum bay width is a 14’-9” wide (contact your
Belanger® Sales Representative for additional options if this is a restriction).
Ideal bay length is 37’-0”. Minimum bay length is 32’-0” (contact your Belanger®
Sales Representative for additional options if this is a restriction).
OPERATION – Minimum operating bay height is 140”. Maximum recommended
vehicle height is 84” (contact your Belanger® Sales Representative for
additional options if this is a restriction).
INSTALLATION – Ideally, for installation, the bay should provide at least
enough height clearance to raise the bottom of the head beams 133” off the
floor with 2 forklifts. See Building Height Considerations on page 3-14 of this
chapter.
Before installing the frame, see the beginning of Chapter 6 to
plan for how the frame may need to be fabricated or modified
for each specific site.
The working envelopes Floor Mounted frames along with all
other components are covered on the 11 x 17 support pages
supplied at the end of this manual.
