Belanger FreeStyler - ON;OFF Controller & over Temp Thermostat Device Connections

INSTALLATION AND STARTUP
1MANUL220 Belanger, Inc.® * PO BOX 5470. * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681 7-5
Chapter 7 Chemical Delivery and Pumping Station
ON/OFF Controller & Over Temp Thermostat Device Connections
UPPER TERMINAL CONNECTIONS
5L1
5L2
5L3
035
BACK
227
FRONT
X36
BACK
338
FRONT
PROCESS
CONTROL
RB100
LIMIT
CONTROL
CB100L
