Chapter 14 HydroBlade® Assembly Option
HydroBlade® Optional Assemblies – Overview
Typical Circuit Overview
If you have purchased the optional HydroBlade® Low Pressure Feed Kit Assembly, the following
are applications that you can use it for and benefit your carwash:
• Rinse and/or Sealer Wax
• Spot Free R.O. / Low Pressure Feed
• Purge Air
Note: The fitting that is factory installed in the Universal Manifold is based on the options you have
purchased.
Note: See the images below for the fittings that correspond to the various options in the location
circled in the image above.
