Chapter 15 Wheel Cleaning and CTA Options
Wheel Cleaning and Chemical Tire Application (CTA) Options
There are two styles of wheel cleaning options available.
Wheel Stinger® with Freestanding CTA
Wheel Stinger® with On-Board CTA
FEATURE
WHEEL STINGER WITH FREE STANDING CTA
WHEEL STINGER WITH ONBOARD CTA
Water
High volume medium-pressure for optimal cleaning results
High volume medium-pressure for optimal cleaning results
Onboard
Delivery
Manifold
Foam applicators with:
• (3) individual nozzle discs with 5-degree nozzles
on each side that are fully adjustable for pinpoint
cleaning accuracy
Molded, hard plastic, protective sleeve covers with:
• (3) individual nozzle discs with 5-degree
nozzles on each side that are fully adjustable
for pinpoint cleaning accuracy
• CTA delivery applicators
• Onboard photo eyes
• Sensors to notify the operators if a fault occurs
Free
Standing
Items
• Pump platform with HydroMinder holding tank
• Bay entrance CTA applicators
• Sensors to notify the operators if a fault occurs
• Pump platform with HydroMinder holding tank
How does it
work?
Applies tire cleaning chemical through floor-mounted
Freestanding CTA applicators at the bay entrance. During
the FreeStyler® wash process, the onboard delivery
manifolds automatically activate delivering a medium-
pressure tire cleaning blast, washing away any remaining
tire debris and providing effective cleaning results on all
types of vehicle tires.
Uses both the treadle and the photo eyes to identify the
exact position of the vehicle's tires. The Onboard CTA
then applies the tire cleaning chemical in one cleaning
pass, followed by a medium-pressure water blast in a
second cleaning pass. Provides effective cleaning results
on all types of vehicle tires.
