Chapter 3 Getting Started
FreeStyler® Position Considerations
Note: Using the previously stated considerations and the site overview, determine if the machine needs to be
installed off-center from the doors, and/or if either side arm will need to be de-stroked to maintain
clearance. Record the information below.
Considering the length, width and height issues previously discussed, answer the following questions.
Summary of Width Considerations
Record Here
P
From centerline of door to the passenger side wall
D
From centerline of door to the driver side wall
I will need to de-stroke the passenger side arm
YES
NO
I will need to de-stroke the driver side arm
YES
NO
I would like to align the center of the rails to the center of the doors
YES
NO
If not, shift the center of the rails towards the….
Driver side
Passenger side
How Far (inches)
Summary of Length Considerations
Record Here
What is the maximum length vehicle you plan to wash?
4-Legged Frame: Treadle and vehicle should be set to factory spec of 9” behind entrance
side of exit 4 x 6 leg
YES
NO
6-Legged Frame: Treadle and vehicle should be set to factory spec of 49” behind entrance
side of exit 4 x 6 leg
YES
NO
If no, will I move the Treadle forward (toward the exit)?
YES
NO
How Far (inches)
Will I have to move the End Limit Stop?
YES
NO
How Far (inches)
Will I need “Small Bay” software?
YES
NO
Using the above width and length consideration charts and the two layout drawings, determine the exit
leg position in the bay.
Note: The head beams are 190” long and made for buildings 16’-0” (192”) or greater. If P + D is less
than 192” in the area of the head beams, they must be cut to a length 2” shorter than P + D.
