Belanger FreeStyler - Check the Remaining Outputs

INSTALLATION AND STARTUP
22-18 Belanger, Inc.® * PO BOX 5470. * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL220
Chapter 22 Initial Startup
Check the Remaining Outputs
1) From the HMI (E-1063 Human Machine Interface), activate the exit arms by turning on EXIT
ON and EXIT BOTH.
 Verify that both arms move in and that water is supplied to both arms.
 Turn the exit arms off.
2) From the HMI (E-1063 Human Machine Interface), activate the Top Wheel by turning on Top
on and Top down.
 Verify that the water spray nozzles are flowing and that the Top Wheel comes down.
Note: If the Top Wheel does not come down, confirm that there is grease on the gears and that the
rotation direction is correct.
 Turn off TOP DOWN so that the Top Wheel rises.
Note: If the Top Wheel “bangs” while going up, close the Top Wheel air flow control located on
the corresponding cylinder and try again.
Note: If the Top Wheel does not go all the way up, slightly open the flow controls (the flow controls
alter the Top Wheel retract speed).
3) From the HMI (E-1063 Human Machine Interface), activate the entrance arms by turning on
the ENTER ON and ENTER BOTH.
Note: Verify that the Entrance Wheels move in and that the water spray nozzles are flowing in the
desired path.
 Turn on ENTER D/S and ENTER P/S.
 Verify the 2” stroke of each corresponding cylinder.
Note: DO NOT CHANGE THE FLOW CONTROLS ON THE ENTRANCE OR EXIT WHEELS
YET. This adjustment is done after the final settings of air pressure penetration and bearing
slope.
 From the Output Board, force on the following lights one at a time and verify operation:
Outside Sign
In-Bay Sign
STOP ENTER
FWD EXIT
SLOW ENTER
STOP EXIT
BWD EXIT
 Force on RNS/WAX WTR and DA CHEM. Verify water and chemical flow
 Force on the SPOT FREE and test (if applicable)
 Force on TIRE HIGH and verify proper operation (if applicable)
 Force on TIRE APP if CTA was purchased and verify proper operation.
 Force on UNDERCARRIAGE and verify proper operation (if applicable).
 Force on ENTER DOOR and EXIT DOOR. Verify proper operation (if applicable).
 Force on DRYER and check rotation according to the Dryer manual (if applicable).
