INSTALLATION AND STARTUP
1MANUL220 Belanger, Inc.® * PO BOX 5470. * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681 13-7
Chapter 13 Water Softener Option
Model 213S OD / WA and WB Connections
Installing the Brine Valve
After adjusting the adjuster tube and the float cup, install the brine valve assembly in the brine drum.
• Locate the brine valve in the brine well so that the bent tube is along the back of the brine well away from the brine
drum wall.
• The bent tube snaps into a notch and extends from the brine drum about 1".
Note: Do not drop the brine valve into the drum!
Note: Dropping may lower the float cup, resulting in an improper setting.
