BONFIGLIOLI Agile User Manual

Commissioning
6.7.3 Fan or pump with closed control loop
Parameters
Recommenced setting
30
Configuration
110 IM: sensorless control (V/f characteristic)
480
Fixed frequency 1
0 Hz
418
Minimum frequency
10 Hz
419
Maximum frequency
53 Hz
420
Acceleration (clockwise)
5 Hz/s
421
Deceleration (clockwise)
-0.01 Hz
440
Operation mode actual value failure
1 - active, fixed frequency 1
441
Max. I component
50 Hz
442
Maximum frequency
53 Hz
443
Minimum frequency
0 Hz
444
Amplification
1
445
Integral time
1000 ms
446
Derivative time
0 ms
447
1st Blocking frequency
0 Hz
449
Frequency Hysteresis
0 Hz
475
Reference frequency source 1
30 - Technology Controller (PID controller)
476
Reference percentage source 1
2 - Analog Value MFI2A
478
Actual percentage source
1 - Analog Value MFI1A
480
Fixed frequency 1 (in case of actual
value failure)
0 Hz
492
Reference frequency source 2
0 - zero
493
Operation mode (reference frequency
source)
1 - (+/- reference)
494
Reference percentage source 2
0 - zero
495
Operation mode (reference percentage
source)
2 - positive only
606
Type V/f characteristic
2 - quadratic
618
Backlash
0%
630
Operation mode (P68&P69=1
|P68&P69=0) (stopping behavior)
0 - (Coast to Stop | Coast to Stop)
651
Operation mode (auto start)
0 - Off
1550
Operation mode energy saving function
Automatic
1552
Energy saving function on
163 - Reference Frequency reached
68
Start Clockwise
71 - IN1D
69
Start Anticlockwise
72 - IN2D
531
Operation mode OUT1D (X13.5) (digital
output)
2 - Run signal
532
Operation mode OUT2D (X10/relay)
103 - Inv. error signal
101
Applications 06/2013 Operating Instructions
