BONFIGLIOLI Agile User Manual

Options
12.2.2 Shield sheet for motor cables
With an optional shield sheet, the shield of the motor cable can be connected to PE potential.
12.2.2.1 Size 1 and 2 (3~: 0.18 kW to 5.5 kW; 1~: 0.09 kW to 2.2 kW)
Valid for the following devices
Frequency inverter
Type
Agile 202
Agile 402
Mains supply
1ph.
3ph.
3ph.
Power
kW
kW
kW
-01 1
0.09
0.18
--
-02 1
0.12
0.25
0.25
-03 1
0.18
0.37
0.37
-05 1
0.25
0.55
0.55
-07 1
0.37
0.75
0.75
-09 1
0.55
1.1
1.1
-11 1
0.75
1.5
1.5
-13 1
1.1
2.2
2.2
-15 2
1.5
3.0
3.0
-18 2
2.2
4.0
4.0
-19 2
--
--
5.5
• Assemble the shield sheet (1) together
with the fixing bracket (2) onto the
mounting plate (3).
1
2
3
293
Shield sheets 06/2013 Operating Instructions
Agile
