Parameter descriptions
Select NPN or PNP according to the required evaluation of the thermal contact.
If a thermal contact is connected to multifunction input 2, no change of
Thermal contact for P570
204 and Operation Mode MFI2 562 is required in the factory setting. You only have to set up the
required evaluation via parameter
Operation Mode Motor Temp. 570.
7.6.6.10 n-/T-control changeover
164 n-/T-Control Change-Over
T
he field-orientated control procedures in configurations 410 and 610 contain the functions for speed
or torque-de
-p
endent control of the drive. The changeover can be done in ongoing operation, as an
additional functionality monitors the transition between the two con-
t
rol systems. The speed controller
or the torque controller is active, depending on the
n-/T-Control Change-Over 164.
F
or information on how to set up the speed controller, refer to chapter 7.9.5.3 "Speed controller".
For information on how to set up the torque controller, refer to chapter 7.9.5.2 "Torque controller".
Parameter
Factory setting
n-/T-Control Change-Over 164
7 - Off
7.6.6.11 Dataset changeover
70 Data Set Change-Over 1
71 Data Set Change-Over 2
Parameter values can be stored in four different data sets. This enables the use of various parameter
values depending on the current operation point of the frequency inverter. The changeover between
the four data sets is done via the logic signals assigned to the parameters
Data Set Change-Over 1
70 and Data Set Change-Over 2 71.
Addressing
Data Set Change-
Over 1 70
Data Set Change-
Over 2 71
Active data set
0
0
Data set 1 (DS1)
1
0
Data set 2 (DS2)
1
1
Data set 3 (DS3)
0
1
Data set 4 (DS4)
0 = contact open 1 = contact closed
Parameter
Factory setting
Terminal
Data Set Change-Over 1
70
73 - IN3D X11.6
Data Set Change-Over 2 71
7 - Off
-
The actual value parameter Active Data Set 249 shows the selected data set.
Save in a data set: parameter values that are measured during Setup
• Select "Setup" manually in menu of operator panel.
The data set selection is displayed.
− Select data set 0 if all data sets are to contain the same parameter values.
− Select one of the data sets 1 ... 4 for commissioning of several motors or for different operating
points.
Example: For auto set-up (auto-tuning) and motor data, select data set 1.
Data set

ENT
 
ENT
 
 
.
.
.
203
Control inputs and outputs 06/2013 Operating Instructions
Agile
