12.3
Brake resisto
r
The brake resistors convert the regenerative energy into heat when the drive is braking.
The resistor must be selected according to the duty cycle and braking power.
Mains
vol
t-
age
Typ
3
Resistor
Continu-
ous power
Maximum
permiss
i-
ble ope
r-
ating
voltage
Integrated
thermal prote
c-
tion
Value
Rated power
V
Ω
kW
W
V
230
BR 160/100
100
1,6
160
900
Optional
230
BR 432/37
37
4,3
432
900
Optional
230
BR 667/24
24
6,6
667
900
Ja
230
BR
1332/12
12
13,3
1332
900
Ja
400
BR 213/300
300
2,1
213
900
Optional
400
BR 471/136
136
4,7
471
900
Optional
400
BR 696/92
92
6,9
696
900
Ja
400
BR 1330/48
48
13,3
1330
900
Ja
400
BR 2000/32
32
20
2000
900
Ja
400
BR 4000/16
16
40
4000
900
Ja
400
BR
8000/7
7,5
80
8000
900
Ja
295
Brake resistor
06/201
3
