Parameter descriptions
7.10.9 System data
For monitoring the application, process parameters are calculated from electrical control parameters.
389 Factor Actual System Value
1543 Base Parameter Actual System Value
Actual values (e.g. actual frequency, torque) can be scaled. The drive can be monitored via the actual
value
Actual System Value 242.
The actual value to be monitored and scaled must be selected. For parameter
Base Parameter Actual
System Value
1543, the number of the actual value parameter must be set. The value of the actual
value parameter is multiplied by the
Factor Actual System Value 389 and can be read out via param-
eter
Actual System Value 242.
Actual System Value 242 = (actual value from parameter 1543) x Factor Actual System Value 389
No. Description Min. Max. Fact. sett.
389 Factor Actual System Value -100.000 100.000 1.000
1543
Base Parameter Actual Sys-
tem Value
Parameter number
of actual value
0 1600
Factory setting:
Actual System Value 242 = (Actual Frequency 241) x 1.000
• Set an actual value (parameter number) in parameter
Base Parameter Actual System Val-
ue
1543.
• Set a factor in parameter
Factor Actual System Value 389.
Parameter
Actual System Value 242 shows the scaled actual value.
7.10.10 Service interval monitoring
Refer to chapter 10.3 “Monitoring of service interval”.
7.10.11 Copy parameters
Parameter values can be saved on a memory card via operator panel or via PC control software VPlus.
Note:
Field bus communication is not possible or faulty during data storage or data reading by means of the
memory card.
Note:
To use the copy function, use the memory card (“Resource pack”) offered by Bonfiglioli Vectron.
Bonfiglioli Vectron doesn’t take any responsibility for the malfunctioning of the memory cards of other
manufacturers.
253
Special functions 06/2013 Operating Instructions
Agile
