Technical data
11.2.2 AGL202 (3~:0.75 to 2.2 kW, 1~:0.37 to 1.1 kW, 230 V)
Type
230 V
Agile 202
-07
-09
-11
-13
Size
1
Output motor side
Selected Mains supply
1ph
3ph
1ph
3ph
1ph
3ph
1ph
3ph
Recommended
motor shaft power
P kW 0.37 0.75 0.55 1.1 0.75 1.5 1.1 2.2
Output current
I
A
2.0
3.5
3.0
5.0
3.5
6.0
5.0
9.0
Long-term
overload current (60 s)
I A 3.0 5.25 4.5 7.5 5.25 9.0 7.5 13.5
Short-time
overload current (1 s)
I A 4.0 7.0 6.0 10 7.0 12.0 10.0 18.0
Switching frequency
f
kHz
2, 4, 8, 16
Output, brake resistor
Minimum brake resistor
R
Ω
100
100
100
100
37
37
37
37
Recommended brake resistor
(385 V)
R Ω 100 100 100 100 92 63 70 41
Input mains side
Rated current
I
A
4.2
3.4
5.3
4.9
7.6
6.5
11.2
9.5
Maximum mains current
1)
I
A
5.5
5.1
6.9
6.7
11.4
10.8
15.5
14.5
Fuses
I
A
6
6
6
6
10
10
16
16
Fuses UL type
I
A
Bussmann FWP-10A14Fa
Mechanics
Dimensions
2)
HxWxD
mm
200 x 60 x 170
Weight (approx.)
m
kg
1.1
Degree of protection
-
-
IP20 (EN60529)
Terminals A mm
2
Mains and motor
terminals:
0.2 … 4 (flexible with sleeve)
0.2 … 6 (rigid)
Terminals relay out-
put:
0.1 … 1.5
Installation
-
-
vertical
Interior fan
-
-
no
Heat sink fan
-
-
yes
Ambient conditions
Power dissipation (2 kHz
switching frequency)
P W 53 53 70 70 89 89 122 122
1) According to DIN EN 61800-5-1.
2) Dimensions of the basic device. Comply with the notes of the assembly variants in chapter 4.2
“Installation” for the standard assembly and chapter 12.9 “Assembly variants”.
280
Operating Instructions
Agile 06/2013 Device data
