Parameter descriptions
The control facilities of the operator panel are not locked. For the restriction of control facilities refer
to chapter 7.5.1 “Reference frequency channel”, 7.5.2 “Reference percentage channel” and 7.3.1
“Control”.
7.1.4 Programming
34 Program(ming)
The parameter
Program(ming) 34 enables acknowledgment of a fault message and resetting to the
factory settings.
A hardware reset is done (Behavior like Mains-Off/Mains-On).
4444 - Default
The parameters of the selected configuration, except for a few excep-
tions, are reset to the default settings. The display of the control unit
Parameters Control level 28 and Configuration 30 are not changed during resetting
to factory settings
(Program(ing) 34 = 4444).
With Keypad Parameter default settings:
Select P34 in Menu Para. Press both arro
w keys to jump to value 4443. Set
P34 to
4444 and confirm with ENT. This sets all parameters to the default values.
7.2 Machine data
The input of the machine data is the foundation for the functionality of the control functions and
methods. You will have to enter the motor ratings during the guided commissioning (setup).
7.2.1 Rated motor parameters
370 Rated voltage
371 Rated current
372 Rated speed
373 No. of pole pairs
374 Rated cosine Phi
375 Rated frequency
376 Rated mechanical power
Parameterize the rated motor data according to the rating plate of the motor of the motor data sheet.
The default settings of the machine parameters are based on the nominal data of the frequency in-
verter and a four-pole asynchronous motor. The machine data required for the control functions and
methods are checked for plausibility and calculated in the course of the commissioning.
Parameter Rated cosine Phi 374 is not available in configuration 610 (synchronous
motors).
370 Rated voltage 0.17⋅U
2⋅U
U
371 Rated current 0.01⋅I
10⋅ o
⋅I
I
ϕ
⋅
⋅
113
Machine data 06/2013 Operating Instructions
Agile
