Commissioning
Select “local” menu for manual operation.
Select "Poti F" (motor potentiometer) menu.
Switch on STOA (X11.3) and STOB (X13.3).
Press RUN button.
The motor is accelerated to the value of P418 (minimum frequency).
Factory setting 3.50 Hz.
Using the arrow keys, set the speed.
Start the drive via signals at control terminals:
Switch on Start clockwise at IN1D (X11.4) or
Start anticlockwise at IN2D (X11.5).
The motor is accelerated to the value of P418 (minimum frequency).
Factory setting 3.50 Hz.
By means of a voltage 0 ... 10 V on MFI1 (X12.3) set the speed. For
potentiometer connection refer to chapter 5.7.1 “Circuit for control
Optional optimization of motor characteristics
The motor characteristics are set correctly for most of the applications with the default settings. In
some cases optimization of the motor characteristics can be necessary or improve the performance
significantly. The optimization possibilities are described in chapter 6.2.10.
6.2.4 Status messages during commissioning (SS…)
The following status messages are possible during commissioning (setup):
Auto setup routine has been carried out.
The plausibility check (PC) of the motor data is active.
The calculation of dependent parameters is active.
The parameter identification demands enable on digital input
STOA and STOB.
Parameter identifica-
tion
The rated motor values are checked by the parameter identifica-
tion feature.
The setup routine via the operator panel is being carried out.
No enable signal. The parameter identification demands enable on
digital input STOA and STOB.
Error during the auto set-up routine. Check the value of Actual
error
259.
The parameter identification feature diagnosed an unbalance dur-
ing the measurements in the three motor phases.
The setup is not carried out until now.
6.2.5 Warnings during commissioning (SA…)
If an error or a warning is signaled during commissioning, the following causes are possible.
SA001 Rated voltage
The value of the parameter Rated Voltage 370 is out of the rated voltage
range of the frequency inverter. The maximum reference voltage is indicat-
ed on the nameplate of the frequency inverter.
SA002 Efficiency
For an asynchronous motor, the calculated efficiency is in the limit range.
Check
370,
371 and
376.
