Technical data
11.2 Device data
This chapter contains the Technical data of the different sizes of the Agile series.
General are valid for AGL202 and AGL402 devices are the following characteristics:
Output motor side
Output voltage
U
V
Maximum value of input voltage, three-phase
Protection
-
-
Short circuit proof and earth fault proof
Rotary field frequency
f
Hz
0 ... 1000, depending on switching frequency
Integrated brake chopper
-
-
yes
Input mains side
Mains configuration
-
-
TT, TN, IT
Mains voltage range U V
AGL202: 230 (-20 %) … 240 (+10 %)
AGL402: 380 (-15%) … 480 (+10%)
Mains frequency
f
Hz
45 ... 69
Overvoltage category
-
-
EN 50178 III, EN 61800-5-1 III
Ambient conditions
Cooling agent temperature (air) T
n
°C
0 ... 40 (EN 60721-3-3),
40 … 55 with power reduction (derating)
Storage temperature
T
L
°C
-25 ... 55
Transport temperature
T
T
°C
-25 ... 70
Relative air humidity - %
Operation:
maximum 85
non-condensing
Storage:
5 … 95
AGL202 devices in the sizes 1 to 3 can be operated either with single phase or three
phase connection. In single pase operation a lower power compared to three phase
operation is available. The type codes correlate to the three phase power.
278
Operating Instructions
Agile 06/2013 Device data
